Vivid Series

ViviD series thermostat has sleek color touch screen and concise user interface which makes interaction smooth and efficient. It provides precise temperature control and enjoy features like nighttime dimmer, confgurable display and scenario mode control. Local schedule and remote control via free mobile app makes it easy to improve comfort and save
energy. For heating application, it is suitable for hydronic floor heating and FCU + hydronic floor heating system. ViviD has one RS-485 port which can be integrated by BA System via Modbus-RTU protocol.

Download
Certification Marks
Features Technical Data Model List Application Installation Diagram

Features

  • Color Touch Screen
  • Configurable Display
  • Brightness Adjustable
  • Nighttime Dimmer
  • Button Lock with User Privilege Access
  • Scenario Mode Control
  • Upon Power Restoration
  • 1 UI for Remote Sensor or Room Card
  • 1 DO for Linked Control
  • Programmable Schedule
  • OnOff Timer
  • Anti-Freezing
  • Configurable Hysterisis
  • OTA
  • Wi-Fi+ RS-485

Technical Data

    • Room Temp Accuracy: +1°C
      Display Temp Resolution: 0.1°C

      Display: Color TFT screen, 480 *320
      Power Consumption: <3W
      Environmental:
           Operating Temperature Range 0-50°C;

           Operating Humidity Range 5-95% RH (no condensation)

      Power Supply: AC85-250V, 50/60Hz

      Terminations: one 2.5mm2 or two 1.5mm2 wires

      Max Load Current: <2A (resistive), <1A (inductive)

      Dim. H x Wx D(mm):86x86x12
      Mounting Hole Dim.:60mm
      Protection Class: IP30

Model List

Model Application Commun ication Certificate FCU/Stage Power Supply IP level Timer Schedule
ViviD-W Floor Heating RS485+WIFI(Tuya) CE - 90-240VAC IP30 - 7 days 4 events
ViviD-FW FCU+Flloor heating RS485+WIFI(Tuya) CE 2-pipe 90-240VAC IP30 - 7 days 4 events

APPLICATION

INSTALLATION DIAGRAM
