DPF1000 Series Dynamic Flow Balance Valve DPF1000-F（DN50-DN500）

Inquiry

Download

Features Specifications Differential Pressure and Flow Dimension Application

Features

When the differential pressure of the system fuctuates, the valve cartridge automatically adjusts the opening of the variableflow channel to achieve constant flow in the controlled area
The precisely calibrated valve core ensures a constant error within 5%
Preset flow in factory, each size has multiple differential pressure ranges selectable
No on-site commissioning required, reduce labor cost

Specifications

Nominal pressure	PN25	Valve body	Ductile cast iron
Connection	Valve cartridge: GB/T 9113.1-2000	Spring	Stainless steel
Flow error	±5%	Sealing	EPDM
Valve catridge	Stainless steel

Differential Pressure and Flow

DN	Differential pressure range (kPa)	Flow range (m³/h)	DN	Differential pressure range (kPa)	Flow range (m³/h)	DN	Differential pressure range (kPa)	Flow range (m³/h)
DN50 DN65 DN80	15~150	2.27 ~ 29.52	DN200	15~150	15.89 ~ 206	DN400	15~150	56.75 ~ 738
	22~210	2.84 ~ 36.36		22~210	19.88 ~ 254		22~210	71 ~ 909
	33~330	3.2 ~ 45.54		33~330	22.4 ~ 318		33~330	80 ~ 1138
	90~900	10 ~ 55		90~900	10 ~ 385		90~900	10 ~ 1375
DN100	15~150	4.54 ~ 59	DN250	15~150	24.97 ~ 324	DN450	15~150	70.37 ~ 1067
	22~210	5.68 ~ 72		22~210	31.24 ~ 399		22~210	88.04 ~ 1127
	33~330	6.40 ~ 91		33~330	35.2 ~ 500		33~330	99.2 ~ 1411
	90~900	10~110		90~900	10~605		90~900	10~1705
DN125	15~150	6.81 ~ 88	DN300	15~150	34.05 ~ 442	DN500	15~150	83.99 ~ 1092
	22~210	8.52 ~ 109		22~210	42.6 ~ 545		22~210	105.08 ~ 1345
	33~330	9.6 ~ 136		33~330	48~683		33~330	118.4 ~ 1684
	90~900	10~165		90~900	10~825		90~900	10~2035
DN150	9.08 ~ 118	15~150	DN350	45.4 ~ 590	15~150
	11.36 ~ 145	22~210		56.8 ~ 727	22~210
	12.8 ~ 182	33~330		64~910	33~330
	10~220	90~900		10~1100	90~900

Dimension

DN	A(mm)	ΦB(mm)	ΦC(mm)	D(mm)	E(mm)	ΦF(mm)	Weight(kg)
DN50	180	50	83	24	-	106	4.4
DN65	180	65	83	24	-	120	4.8
DN80	180	80	83	24	-	132	5.2
DN100	220	100	133	24	-	177	10.2
DN125	220	125	140	24	-	193	14
DN150	220	150	162	24	53	220	19.4
DN200	220	200	214	24	53	280	28.5
DN250	220	250	280	24	53	341	36.3
DN300	223	300	328	24	69	400	54.8
DN350	223	350	382	24	69	448	66
DN400	242	400	440	24	69	510	85.5
DN450	242	450	487	24	69	560	110.8
DN500	242	500	545	24	69	618	149.7

APPLICATION
